Unalloyed Titanium Welding Wires ERTi-4

Titanium Welding Wire Specification

Titanium offers similar strength of steel but is two times lighter and offers a amazing corrosion resistance. Grade 1 is the most pure type and is mostly welded with Grade 2 filler metal. The weldabillity of Titanium is excellent for most grades but extra care have to be taken for the gas protection on the weld pool, the weld pool needs to stay protected until it cooled down to at least?470oC. Often Titanium is welded in a gas chamber with pure argon gas to make sure that the weld pool gets proper protection. Ti-wire high performance welding wires is compliant AWS A5.16/SFA-5.16 standards for aerospace and power.

PRESENTATION OF BAOJI TITANIUM WIRE INDUSTRY CO., LTD.

Baoji Titanium wire industry Co.Ltd,which is AS9100C, ISO 9001:2008 certified manufacturer of titanium bars, titanium wire,titanium welding wire, filler rods, plates, forged parts for 20 years. Both commercial pure titanium and titanium alloys material. Currently our products serve the clients in aerospace, medical, industrial fields etc.

Tips on How to Choose the Right Titanium Grade

titanium wire, titanium bar, titanium plate, titanium sheet, titanium disc, Gr.2, Gr. 5, Ti6Al4V, Gr.7, Gr. 12, industrial use, medical use, chemical use, aerospace, mining applications

Description
Specification

AWS A5.16 Titanium Welding Wire ERTi-4
Tig-Mig Welding wire for Titanium Grade 4

AWS A5.16 Classification:
    ERTi-4

Shape:
   Straight, in spool

Surface Treatment:
    Polished, Pickled

Specifications:
    AWS A5.16, ASTM B863, AMS4951, AMS4954, ASTM F67

Size
    Diameter: From Ø 0.15mm - 6.0mm (Ø 0.006" - 0.236")
    Length:      From 914mm - 2000mm (Ø 36" - 78.75") -- For straight wire
                      From 1kg - 30kgs per spool                       -- For Spool packing

Production Capability:

     72 Metric Tons/month

Packing:
     Straight: sealed with plastic bag in plastic box + plywood case.
   In spool: carton box + plywood case.
     As per customer’s requirement.

Delivery Time:
    5-15 days

Shipping:
    By International Express(TNT, FEDEX, DHL, UPS, etc.), By Air, By Sea

Titanium Welding Wire.pdf

Titanium Welding Wires406.jpg

AWS A5.16/SFA-5.16 Titanium Welding Wire ERTi-4

Category	BTWI-BPTW Solid wires
Type	Solid Titanium welding wire
Applications	ER Ti-4 is developed for welding Titanium grade 1, 2, 3 and 4. This alloy finds his applications in chemical industry and offers excellent Weldabillity.
Properties	The weld deposit is ductile and offers excellent corrosion resistance in oxidizing environments. The unique combination of mechanical strenght and corrosion resistance makes the alloy a prefered choice in many applications to prefend or solve problems. The wire is cleaned in a very special way to obtain porosity free and a ductile weld deposit.
Classification	AWS A 5.16: ER Ti 4
Suitable for	Titanium grade 1, 2, 3 and 4.

Welding Deposit Weight %

C	O	N	H	Fe	Ti
< 0.03	< 0.20	< 0.018	< 0.008	< 0.05	rem

Mechanical Properties:

Heat

Treatment

RP0,2

(N/mm²)

(%)

Impact Energy (J) ISO-V

Hardness

-20°C

-40°C

-60°C

HRc / HV

438

550

Welding parameters / packing

Welding Parameters			Packing
Dia. (mm)	Length (mm)	Current (A)	kg / tube
1.0	914-1000mm		5kgs
1.2	914-2000mm		5-10kgs
1.6	914-2000mm		5-10kgs
2.0	914-2000mm		5-10kgs
2.4	914-2000mm		5-15kgs
3.0	914-2000mm		5-15kgs
3.2	914-2000mm		5-15kgs
3.5	914-2000mm		5-15kgs
4.0	914-2000mm		5-15kgs
4.5	914-2000mm		5-15kgs
5.0	914-2000mm		5-15kgs
6.0	914-2000mm		5-15kgs

Note: Also available as spooled wire :0.8 mm, 1.0 mm and 1.2 mm (D-100 / D-200 / D-300)

ERTi-4 UNS R50130 AWS A5.16 Unalloyed Titanium Welding Wires
